Electrochemical Cell Harvests Lithium from Seawater

Researchers have now developed an economically viable system that extracts high-purity lithium from seawater

by King Abdullah University of Science & Technology
Register for free to listen to this article
Listen with Speechify
KAUST researchers have developed a method to extract lithium, a vital element in autonomous vehicle batteries, from seawater in a more economically viable way.
© 2021 Morgan Bennett Smith

Lithium is a vital element in the batteries that power electric vehicles, but soaring lithium demand is expected to exhaust land-based reserves by 2080. King Abdullah University of Science & Technology (KAUST) researchers have now developed an economically viable system that can extract high-purity lithium from seawater.

The oceans contain about 5,000 times more lithium than the land but at extremely low concentrations of about 0.2 parts per million (ppm). Larger ions, including sodium, magnesium and potassium, are all present in seawater at much higher concentrations; however, previous research efforts to tease lithium from this mixture have yielded little.

The KAUST team solved this problem with an electrochemical cell containing a ceramic membrane made from lithium lanthanum titanium oxide (LLTO). Its crystal structure contains holes just wide enough to let lithium ions pass through while blocking larger metal ions. "LLTO membranes have never been used to extract and concentrate lithium ions before," says postdoc Zhen Li, who developed the cell.

The cell contains three compartments. Seawater flows into a central feed chamber, where positive lithium ions pass through the LLTO membrane into a side compartment that contains a buffer solution and a copper cathode coated with platinum and ruthenium. Meanwhile, negative ions exit the feed chamber through a standard anion exchange membrane, passing into a third compartment containing a sodium chloride solution and a platinum-ruthenium anode.

The researchers tested the system using seawater from the Red Sea. At a voltage of 3.25V, the cell generates hydrogen gas at the cathode and chlorine gas at the anode. This drives the transport of lithium through the LLTO membrane, where it accumulates in the side-chamber. This lithium-enriched water then becomes the feedstock for four more cycles of processing, eventually reaching a concentration of more than 9,000 ppm. Adjusting the pH of this solution delivers solid lithium phosphate that contains mere traces of other metal ions—pure enough to meet battery manufacturers' requirements.

The researchers estimate that the cell would need only US$5 of electricity to extract 1 kilogram of lithium from seawater. The value of hydrogen and chlorine produced by the cell would more than offset this cost, and residual seawater could also be used in desalination plants to provide freshwater.

"We will continue optimizing the membrane structure and cell design to improve the process efficiency," says group leader Zhiping Lai. His team also hopes to collaborate with the glass industry to produce the LLTO membrane at large scale and affordable cost.

- This press release was originally published on the KAUST Discovery website. It has been edited for style
