WATERBURY, CT — February 26, 2021 — As a world leader in compact linear motion systems, Haydon Kerk Pittman, a business unit of AMETEK® Advanced Motion Solutions division, is pleased to announce the release of the new Z-Theta motion platform. The Z-Theta offers linear and rotary point-to-point motion in a compact footprint, providing flexibility, value, durability, and performance suited for a host of lab automation, semiconductor, and light factory automation applications.
The Z-Theta’s highly configurable design is ideal for easy integration into original equipment manufacturers’ assemblies. Unlike in-house designs comprised of multiple components that require added engineering, vendors, and assembly integration, Z-Theta is a modular “bolt-in” package that allows customers to benefit from reduced complexity.
Advanced Lab Management Certificate
The Advanced Lab Management certificate is more than training—it’s a professional advantage.
Gain critical skills and IACET-approved CEUs that make a measurable difference.
At its core, Z-Theta features the patented ScrewRail® linear actuator, which combines guidance and linear transmission in a slender co-axial profile. Haydon Kerk Pittman’s unique dual-motion integration with a pair of stepper motors adds rotary (theta) motion in a manner that reduces motion system size by 50-80 percent and provides as much as a 60 percent overall cost reduction when compared to traditional design approaches.
Customers can further customize Z-Theta for their specific performance needs with a variety of lead screw resolutions, available free-wheeling and anti-backlash nut selections, stepper motor configuration options, and optical encoder line counts.
For more information, please contact David Kosewski, Haydon Kerk senior product line manager.
