A Portable Measuring Device to Detect Optimum Ripeness in Tomatoes

A study by the UPV/EHU-University of the Basque Country is applying a portable device based on the Raman spectroscopy technique to monitor the ripeness of tomato fruits

by University of the Basque Country
Register for free to listen to this article
Listen with Speechify

Josu Trebolazabala Josu Trebolazabala analyzes the composition of a tomato using a Raman spectrometer.Photo credit: Txetxu BerruezoThe portable Raman spectrometer, a device used in very different fields such as metallurgy, archaeology, and art, allows data to be obtained on the variation in the composition of the tomato fruit during its various ripening phases, according to the results of a study conducted in the UPV/EHU's Department of Analytical Chemistry. The portable Raman spectrometer is an instrument widely used in a whole range of sectors, because it is a non-invasive technique that can be used, for example, to observe the pigments present in a painting or a sculpture without having to extract any samples, thus preserving the integrity of the work in question. In this case, a research team of the UPV/EHU has applied this equipment to culinary research. According to Josu Trebolazabala, the author of the study, "it is about transferring this technology, which had a specific use, to the kitchen. Our idea was to come up with a tool that could help producers find out when their tomatoes have reached their optimum ripeness point. This is achieved by using this technique and, what is more, without destroying the fruit."

Related Article: Infrared-Based Peeling of Tomatoes May Improve Precision, Save Water

The results provided by this portable instrument have been compared with those provided by a similar laboratory instrument, and "even though the quality of the Raman spectra of the lab instrument was higher, the quality of the information provided by the portable instrument could be regarded as sufficient for the aim in mind. The aim is to enable producers to go to the vegetable plot with this equipment, place the Raman probe on the tomato, and find out whether it is at its optimum picking point or whether it needs to be left longer so that it can ripen properly," Trebolazabala said.

Tomato ripening

The monitoring of the composition of the tomato fruit during its ripening phases has made it possible to observe the changes that take place in the composition of the tomato during its passage from an unripe state towards a ripe state. "When the tomato is green, the main pigments are chlorophyll (hence its green color) and the waxy cuticles, which are on the outside," Trebolazabala explained. But the presence of these compounds falls as the fruit reaches its point of optimum ripeness. "Once the color changes to orange-colored, compounds of a different type are observed; the carotenoid compounds are activated. The tomato gradually acquires nutrients until it reaches its optimum point, in other words, when the lycopene (the red carotenoid) is at its maximum level. After that, the tomato begins to lose its carotenoid content, as shown by the analyses conducted on overripe tomatoes."

This innovative technique can be extrapolated to any other food that changes color during its ripening phase. "Tests have been carried out on peppers and pumpkins, for example, and it is also possible to obtain the data on their composition," he explained.
